Main Features and Benefits
This product features a high-resolution 16-bit DAC with up to 1.2 GSPS, capable of generating RF, Acoustic, and Multi-target IQ waveforms. It offers flexible configurations, including programmable pulse width and output levels, while supporting a broad range of external clock frequencies.
- Multiple signal scenarios can be generated like RF, Acoustic, Multi-target as IQ Waveform.
- High-Resolution DAC – 16 bit, Upto 1.2 GSPS.
-
Versatile and flexible with multitude of configuration options:
- Programmable waveform pulse-width, pulses per channel.
- Support for infinite number of pulses.
- Programmable RF output level and center frequency.
- Accepts range of external clock from 10 to 140 MHz.
- Power On Self-test.
- Rugged hardware, dual board system.
- Easy to use GUI for control and configuration.
WATCH THE VIDEO
Arbitrary Waveform Generator – Accurate Signal Testing
Watch how our Arbitrary Waveform Generator brings precision to SAR and UAV testing in this demo. The video highlights its ability to generate RF, acoustic, and multi-target IQ waveforms with programmable configurations and external clock support.
AWG Application
- Easy to use GUI for control and configuration.
-
Military Applications:
- Radar system evaluation
- Electronic warfare (EW) simulations
- LiDAR
- Wireless communication networks
-
Civilian Application areas:
- Telecommunication (Wi-Fi, LTE testing etc.)
- Education (University labs)
- Healthcare
- Electronics
- Industrial
